Future-proof solution for residential use
Future-proof solution for residential use
Description:
- Elegant design meets smart energy.
- Our solar-ready EV charging station offers seamless user experience and full energy management.
- Charge safely, beautifully and sustainability every time
Features:
- Ready to use charger
- Dynamic Load Management
- Charge scheduling
- Photovoltaic charging
Características técnicas
OUTPUT:
- Socket Type 2 with shutters (T2S)
CONNECTIVITY:
- Bluetooth Low Energy (BLE 4.2)
- Wifi Hotspot
- 4G
AUTHENTIFICATION & INTERFACE:
- LED indicator
- Smartphone application
- RFID reader
ENERGY MANAGEMENT:
- Onboard energy meter
- Current transformer
- Dynamic Load Management
- RS485 (for PV /EMS integration, protocol compatible required)
SAFETY:
- Earthing system PH+N+T - TT / TN
- Ingress protection rate IP54
- Impact protection IK10
- Current protection 30mA Type A and RCM 6mA DC
GENERAL SPECIFICATIONS:
- Nominal current 32A
- Nominal input voltage 230V
- Weight 3.1kg
- Dimensions 365201140 mm
- Temperature -30° to 50°C (in use)
